Eletrônica Co. de Shenzhen Shichuangxinke, Ltd
o profissional faz a boa qualidade, fornece produtos e serviço perfeitos para cada cliente.
 |
| Place of Origin: | China |
| Marca: | SCXK |
| Certificação: | CE,ROHS ,FCC,UL ISO2001 |
| Model Number: | SCXK-P4 |
| Minimum Order Quantity: | 1sqm can be available |
|---|---|
| Preço: | Negociável |
| Packaging Details: | the led display can be packaged with wooden box,paper box,flight case |
| Delivery Time: | 7-10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C |
| Supply Ability: | 1000sqm/month. we can make the led display on time |
| cabinet size: | 768mmx768mm | Display Color: | 16.7million |
|---|---|---|---|
| Drive Mode: | 1/16 scan | module size: | 256mm x128mm |
| Color: | full color | warranty: | 3 years |
| power supply: | Meanwell power supply |
HD Full Color Rgb Led Display Board High Refresh Rate 768mmx768mm Cabinet
We insist better quality and after-sales service to our customers.
And guarantee all kinds of service to our cusotmers.
1.The cabinets, featuring great moisture and corrosion proofing,
enable themselves to work in all weather conditions.
2. Superb refresh rate provides you coherent video effects to
meet your needs for high display quality.
3. Superb cost effective offers you both top notch quality
and reasonable price, maximizing the value of your investment
Parameter as follows.
| The full color Indoor P4 led display parameter as follows. | |||||||||
| LED Lamps | Type | SMD2121(High Brightness LEDs) | |||||||
| LED Standard | Real Pixel(1R1G1B) | ||||||||
| Red Wavelength | 625-630nm | ||||||||
| Green Wavelength | 515-530nm | ||||||||
| Blue Wavelength | 465-475nm | ||||||||
| LED Module | Pixel Pitch | 4mm | |||||||
| Module Size | 256mm x128mm | ||||||||
| Module Resolution | 64*32dots | ||||||||
| LED Cabinet | Cabinet Size | 768mmX768mm | |||||||
| Cabinet Resolution | 192pixels *192pixels | ||||||||
| Cabinets Material | Sealed Iron Cabinet | ||||||||
| LED Display | Pixel Density | 62500pixels/sq.m | |||||||
| Drive IC | MBI5024 | ||||||||
| Power Supply | Series connection | ||||||||
| Brightness | >2500cd/sqm | ||||||||
| Display Color | 16.7million | ||||||||
| Viewing Angle | 160°(Horizontal),110°(Vertical) | ||||||||
| Best Viewing Distance | 4m~200m | ||||||||
| Max Power Consumption | 600 w/sq.m | ||||||||
| Average Power Consumption | 300 w/sq.m | ||||||||
| Weight | 40kgs/sq.m | ||||||||
| Refresh Rate | 2000hz | ||||||||
| Input Voltage | AC220V/50H or AC110V/60H | ||||||||
| Output Voltage | DC5V,40A | ||||||||
| Grey Scale Levels | 16bit | ||||||||
| Display Colors | R(1024) x G(1024) x B(1024) | ||||||||
| MTBF | 10,000 hours | ||||||||
| Life-span | 100,000 hours | ||||||||
| Protection Level | IP43 | ||||||||
| Failure percentage of leds | less than 0.0003 | ||||||||
| Working Temperature | -5℃~45℃ | ||||||||
| Drive Mode | 1/16 scaning | ||||||||
| Working Humidity | 10%~99% | ||||||||
As the professional manufacturer, we will guarantee every pieces of the led display will be through the strictly test before
shipment. you can benefit from our long time business cooperation. The led display will be packaged well with wooden box.
Q1. What's the warranty of your LED Display Screen ?
A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2. What about your pre-sale service and post-sale service?
A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
Q3. Whats your payment term? How long it takes to delivery?
A3. We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.Our average Production time is 10 days, after receiving the deposit.
Q4. What's the control system?
A4. For synchronization control. We use Nova, Linsn Or Colorlight control system.
For asynchronous control We use Onbon, or Xixun control system.
