Full Color P6 Outdoor Building Street Billboard Video Wall Large LED Advertising Display Screen

Full Color P6 Outdoor Building Street Billboard Video Wall Large LED Advertising Display Screen

Detalhes do produto:
Lugar de origem: Shenzhen na China
Marca: SCXK
Certificação: CE/ROHS/FCC/ISO/CB
Número do modelo: P6
Condições de Pagamento e Envio:
Quantidade de ordem mínima: 2 pcs
Preço: Negociável
Detalhes da embalagem: Caixa de voo, estojo de madeira, caixa, depende de você.
Tempo de entrega: 7-10 dias úteis após receber seu pagamento
Termos de pagamento: T/T, Western Union
Habilidade da fonte: 5000sqm por mês
Contato
Descrição de produto detalhada
Pitch de pixel: 6mm Tipo de LED: SMD2121
Função de exibição: Vídeo/texto/imagem Impermeável: IP65
MBI: 5024 Ângulo de visualização: H: 160 V: 140
Distância de visualização ideal: >=6m Brilho: 5000CD/㎡
composição de pixels: 1 R1G1B Parâmetro LED: R: 625-630nm
módulo: 192*192 mm
Destacar:

P6 outdoor LED billboard

,

full color LED advertising screen

,

large building video wall display

Full Color P6 Outdoor Building Street Billboard Video Wall Large LED Advertising Display Screen
Product Specifications
Attribute Value
Pixel pitch 6mm
Led Type SMD2121
Display Function Video/Text/Image
Waterproof IP65
MBI 5024
Viewing angle H:160° V:140°
Optimal viewing distance ≥6m
Brightness 5000cd/㎡
Pixel composing 1 R1G1B
LED parameter R:625-630nm
Module 192*192mm
Product Description

Outdoor Building Street Digital Billboard Mounted Video Wall Large LED Advertising Display Screen

Quality Guarantee
  • 3 years warranty - Free replacement and maintenance for spare parts is offered within warranty period. Free maintenance service is offered before product's life expires.
  • Aftersales warranty
  • Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

Even if within the warranty period, if the following occurs, certain maintenance costs will be charged:

  • The malfunction and damaged caused by incorrect use, the unauthorized repairs and alteration.
  • The damage caused by fire, flood, abnormal voltage, other natural disasters and secondary product damage.
  • The product malfunction caused by the fall and transportation failures after purchase.
  • The product malfunction caused by Not in accordance with the user manual operation.
  • The malfunction and damaged caused by the other barriers (man-made factors or external device).

Any problems in the after-sales service, please contact us directly.

Technical Specifications
Parameter Specification
Resolution/mm 6
Pixel configuration 1R1G1B
Pixel density/pixels/m² 27778/m²
Module resolution 32*32
Module size/mm 192x192
View distance 5-400m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >4500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120°
Vertical view angle 60°
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode (1/8)
Frame rate 60Hz
Refresh frequency >3500Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <900W
Average power:/㎡ <350W
Self-check technology LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%
Product Overview
Items Indoor Led display: P1.5 P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P10
Outdoor Led display: P3, P3.91, P4, P4.81, P5, P6, P8, P10, P12, P16, P20, P25
Dance floor led display
DJ led screen
Transparent led display
Material steel, aluminum, die casting aluminum
Certificates CE, FCC, RoHS, CCC, UL
Payment terms 30% deposit before production, 70% balance before shipping
T/T
Western Union
Packing Standard Export Carton with fully Polyfoam or Pearl Wool
Flight case;
Anti-shaking wooden case
Shipping 5 to 7 working days upon receiving deposit payment
After-Sales-Service Lifetime with professional engineer support for free.
Within 5 year, supply spare parts for free if has quality problem (not by man-made damage)
Using Range Shopping mall, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi, and so on.
Full Color P6 Outdoor Building Street Billboard Video Wall Large LED Advertising Display Screen 0
Production Process
  1. Incoming Inspection
  2. SMD
  3. Plug-in
  4. Wave Soldering
  5. After Welding
  6. Testing
  7. Semi Finished Aging
  8. Module Assembly
  9. Gluing
  10. Finished Aging
  11. Detection Finishing Warehousing
Packaging and Shipping

Wooden case or flight case package are available.
Shipping by sea, air or DHL, multiple shipping ways for your choice.

Our Advantages
  • Professional Manufacturer of led display
  • OEM service, No MOQ
  • Easy installation, regular items in Stocks
  • Offering free design drawing as requested
  • Remote controlling and adjusting are available
  • Wooden case or flight case, you are the boss
  • Your reply will be replied within 24 hours
  • Fast delivery: Usually 6-8 working days
  • Excellent R&D team, factory Price and assure you quality goods
Why Choose Us

Continues Quality
With more than 10 years experience in led display producing, equipments are updated regularly. What's more, unique standardized and module production ensure our products continuous quality.

Competitive Price
With large scale production capacity and professional production technology, our company have built effective modular production. We always stick to promote the technical innovation and reduce cost to benefit customers.

Fast Delivery
Once we promise the delivery date, we will try our best to fulfill it. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service
Pre-sales: Your purchasing requirements will be highly valued and we'll recommend suitable products to you.
After-sales: We will track the products usage and then constantly perfect our products.
